Payload
Dual gimbal: visible-light + thermal.
Visible camera: 1/2-inch CMOS (48 MP) `{`for visible side`}`.
Aperture (visible): f/2.8 (fixed).
Thermal camera: 640 × 512 resolution.
Thermal lens: 9.1 mm focal length.
Thermal FOV: ~ 61°.
Radiometric temperature measurement: –20°C to 150°C (high gain) / 0°C to 550°C (low gain).
Temperature accuracy: ±3°C or ±3% (whichever is greater).
Thermal focusing range: ~2.2 m to infinity.
Connectivity
Transmission / Range: up to 12 km in ideal conditions.
Frequency bands: 2.4 GHz / 5.2 GHz / 5.8 GHz.
Obstacle Avoidance: 3-way binocular vision (forward, backward, downward).
AI Target Recognition & Positioning: yes (identifies objects like people, vehicles).
Speed
Maximum horizontal speed: ~ 18 m/s.
Max ascent / descent speeds (various modes): <depends on mode, e.g., 5 m/s ascent typical).
Flight endurance (no wind): ~ 40 minutes.
Wind resistance: “fresh breeze” / level in that class.
Dimensions
Weight (with battery & props): ~ 866 g.
Folded dimensions: 210 × 123 × 95 mm.
Unfolded dimensions: 433 × 516 × 95 mm.
Max rotation speed (motor): 8,000 rpm.
